24kV SF6 Gas Insulated Switchgear
To buy high quality 24kV SF6 Gas Insulated Switchgear, you can choose Taili as your manufacturer and enjoy our factory prices. It is a medium-voltage switchgear that utilizes SF6 gas for high insulation and efficient arc extinguishing, and seals all high-voltage components within a grounded metal enclosure.
24kV SF6 Gas Insulated Switchgear is a durable product from Taili factory, and is characterized by its compactness, reliability, safety, and maintenance-free nature. It has become the preferred solution in modern power distribution systems, especially in environments with harsh conditions or limited space.
Technical Specification
| Items | Unit | Unit C | Unit F | Unit V / 630A | Unit V / 1250A | ||
| Load breaker | Combined components | VCB | Disconnector/ earthing switch | VCB | Disconnector/ earthing switch | ||
| Rated voltage | kV | 24kV | |||||
| Rated frequency | Hz | 50/60 | |||||
| Frequency withstand voltage(phase-phase/ breaker port) | kV | 24kV : 50/65 | |||||
| Lightning impulse withstand voltage | kV | 24kV : 125/145 | |||||
| Rated current | A | 630 | 125 | 630 | 630 | 1250 | 1250 |
| Rated short-circuit closing current(peak) | kA | 50/63 | |||||
| Rated short withstand current | kA/4s | 20/25 | |||||
| Loop resistance | Ω | ≤300 | |||||
| Mechanical life | times | 5000 | 5000 | 10000 | 5000/3000 | 10000 | 5000/3000 |
| Circuit breaker unit rated operating sequence | / | 0-0.3S-C0-180S-CO | |||||
| Protection class (airbox) | / | IP67 | |||||
| Protection class (enclosure) | / | IP4X | |||||
| Rated annual air leakage rate | % | 0.01 | |||||
Drawing and dimensions of SF6 Insulated Switchgear
Please provide the following information, and we will be able to offer better services.
| Product application scenarios | |
| Product technical parameters |
The aspects that need attention
1. Environmental impact of SF6 gas: SF6 is a clearly defined potent greenhouse gas under the Kyoto Protocol. Its global warming potential (GWP) is 23,900 times that of CO₂. Therefore, at the final disposal stage of the equipment's life cycle, professional recovery devices must be used to recover and purify the gas, and direct discharge into the atmosphere is strictly prohibited.
2. Complex fault repair: In case of internal faults, professional equipment, technology, and personnel are required to carry out processes such as gas recovery, vacuum pumping, and gas filling. The repair process is more complex than that of air-insulated switch cabinets of the same voltage level, and high skills are required for the personnel.
3. Higher cost: The initial equipment investment is usually higher than that of air-insulated switch cabinets of the same voltage level.
